Upgrade your electrical fabrication with our high-precision Fiber Laser Busbar Marking Machine. Engineered for the Canadian power distribution industry, this system delivers permanent, high-contrast engraving on copper and aluminum busbars. Perfect for 2D Data Matrix codes, serial numbers, and CSA safety logos. Maintenance-free fiber source with high-speed processing for switchgear and transformer manufacturing. Request a quote for expedited shipping to Ontario, Alberta, and Quebec.
The LTMC fiber laser busbar marking machine is a non-contact, maintenance-free engraving system built for Canadian switchgear, transformer and power-distribution shops that need permanent, high-contrast CSA/UL logos, serial codes and 2D Data Matrix on copper and aluminum bars. It offers 20 W, 30 W or 50 W fiber sources at 1064 nm, marking areas up to 300 × 300 mm at speeds to 7000 mm/s with a 0.01 mm minimum line width. Running on 110 V/220 V 50–60 Hz with air cooling and a source life up to 100,000 hours, it handles 3–15 mm busbars and integrates with CNC fabrication lines.
Fiber Laser Busbar Marking Machine — Laser power output: 20 W / 30 W / 50 W. Test condition: fiber source tuned for high-reflectivity copper/aluminum. Result: selectable 20 W, 30 W or 50 W source. Baseline: matches the fiber laser row in family_ref.txt (20/30/50 W).
Fiber Laser Busbar Marking Machine — Marking scope: 110 × 110 / 200 × 200 / 300 × 300 mm. Test condition: galvo field lens coverage. Result: up to 300 × 300 mm markable area. Baseline: matches the fiber laser row in family_ref.txt (110/200/300 mm); larger than the LT-PM100 dot-peen area of 150 × 100 mm (aid 199).
Fiber Laser Busbar Marking Machine — Marking speed: ≤7000 mm/s. Test condition: high-speed non-contact etching. Result: up to 7000 mm/s. Baseline: matches the fiber laser row in family_ref.txt (≤7000 mm/s).
Fiber Laser Busbar Marking Machine — Minimum line width: 0.01 mm. Test condition: fine marking on conductor surface. Result: 0.01 mm minimum line width. Baseline: matches the fiber laser row in family_ref.txt (0.01 mm); finer than the dot-peen process, which is limited by stylus size.
Fiber Laser Busbar Marking Machine — Power supply: 110 V/220 V 50–60 Hz. Test condition: shop outlet connection. Result: 110 V or 220 V single-phase, 50–60 Hz. Baseline: matches the fiber laser row in family_ref.txt (110/220 V); the dot-peen LT-PM100 (aid 199) also runs 110/220 V but needs 0.3–0.6 MPa air.
No — it runs on 110 V/220 V single-phase, 50–60 Hz, standard shop power, separate from the 600 V busbar machine supply. Confirm your site voltage with our team.
It engraves CSA/UL safety logos and 2D Data Matrix, and is offered in open-table or fully enclosed Class 1 configs with laser safety goggles and fume extractors to meet Canadian Ministry of Labour standards. Confirm the enclosure option with our team.
We provide video training, remote technical support, English manuals and on-site commissioning via regional partners; Raycus/MAX/IPG sources and spare galvo or lens parts are available. Confirm lead times with our team.
Discover the next generation of Copper Busbar Laser Marking Machines, engineered for the rigorous demands of the Canadian electrical manufacturing sector. This professional-grade fiber laser system provides rapid, high-contrast, and non-removable engraving on both copper and aluminum conductors. Whether integrated into a full busbar machine production line or used as a standalone station, this technology ensures precision traceability for switchgear, power distribution units, and transformer assemblies.
High-Speed Fiber Laser Source: Specifically tuned for high-reflectivity metals like copper and aluminum.
Permanent Compliance Marking: Effortlessly engrave CSA/UL safety logos, serialized batch codes, dynamic QR codes, and 2D Data Matrix symbols.
Heavy-Duty Capacity: Optimized for busbar thicknesses ranging from 3mm to 15mm.
Non-Contact Thermal Control: Advanced beam delivery prevents material deformation, localized annealing, or burn marks on sensitive contact surfaces.
Seamless Shop Integration: Fully compatible with automated CNC busbar fabrication equipment for high-efficiency workflows.
Maintenance-Free Operation: Designed with a long-life laser source (up to 100,000 hours) to minimize downtime in busy Canadian production shops.
| Technical Parameter | Specifications |
|---|---|
| Laser Power Output | 20W / 30W / 50W (Optional) |
| Laser Wavelength | 1064nm |
| Marking Scope | 110mm x 110mm / 200mm x 200mm / 300mm x 300mm |
| Marking Speed | ≤7000mm/s |
| Minimum Line Width | 0.01mm |
| Minimum Character Size | 0.15mm |
| Cooling Method | Built-in Air Cooling |
| Power Supply | 110V/220V 50-60Hz |
This high-precision system is the ideal choice for Canadian facilities specializing in:
HVAC & Power Distribution: Precise marking of phase identifiers and voltage ratings.
Renewable Energy Systems: Durable labeling for solar inverters and wind turbine busbars.
Electric Vehicle (EV) Infrastructure: High-speed marking of battery pack conductors.
Custom Switchgear Shops: Professional branding and circuit diagram engraving directly on the metal.
Combine this with our CNC busbar punching and cutting machines to create a fully automated "Industry 4.0" production cell.
| Main Component | Brand/Standard | Function |
|---|---|---|
| Fiber Laser Source | Raycus / MAX / IPG | Generates high-intensity laser beam for metal etching |
| Digital Galvo Scanner | High-Speed Sino-Galvo | Directs the laser beam with extreme precision |
| F-Theta Field Lens | Precision Optical Grade | Focuses laser across the entire marking area |
| Control System & Software | EzCad (English Version) | Supports PLT, DXF, AI, JPG, and customized CAD files |
| Lifting Column | 500mm Manual/Auto | Adjusts focus for different busbar thicknesses |
| How does fiber laser marking compare to traditional inkjet labeling for Canadian winters? | Laser marking is a structural change to the metal surface. Unlike labels or ink, it will never peel, fade, or corrode, even in extreme Canadian temperatures or high-humidity environments. |
| Is the machine safe for use in an open shop environment? | We offer both open-table and fully enclosed (Class 1) safety configurations. All machines can be equipped with laser safety goggles and fume extractors to meet Canadian Ministry of Labour safety standards. |
| Can it mark on tinned or nickel-plated copper busbars? | Yes. The fiber laser parameters can be adjusted to mark through coatings or to create a high-contrast mark on the plating itself without compromising the underlying material. |
| Do you provide local training and setup support in Canada? | We provide comprehensive video training, remote technical support, and English-language manuals. On-site commissioning can be arranged through our regional partners. |
